DROPPER POST
Dropper Post
SP
O.D.
30.9 mm, 31.6 mm, 34.9 mm
Cartridge
Air/Oil Cartridge
Compatible Levers
RLV01
RLH01
RLH02
RHL02 Details
Angle Adjustable
Position Adjustable
Specifications
| MODEL NO. | O.D. (MM) | TRAVEL (MM) | LENGTH (MM) | CARTRIDGE | MIN. INSERT (MM) | WEIGHT |
|---|---|---|---|---|---|---|
| SP30980 | 30.9 | 80 | 306 | Air/Oil Cartridge | 90 | 485g |
| SP309100 | 30.9 | 100 | 346 | Air/Oil Cartridge | 90 | 513g |
| SP309125 | 30.9 | 125 | 396 | Air/Oil Cartridge | 100 | 565g |
| SP309150 | 30.9 | 150 | 458 | Air/Oil Cartridge | 100 | 665g |
| SP309170 | 30.9 | 170 | 492 | Air/Oil Cartridge | 100 | 693g |
| SP31680 | 31.6 | 80 | 306 | Air/Oil Cartridge | 90 | 500g |
| SP316100 | 31.6 | 100 | 346 | Air/Oil Cartridge | 90 | 528g |
| SP316125 | 31.6 | 125 | 396 | Air/Oil Cartridge | 100 | 580g |
| SP316150 | 31.6 | 150 | 458 | Air/Oil Cartridge | 100 | 680g |
| SP316170 | 31.6 | 170 | 492 | Air/Oil Cartridge | 100 | 708g |
| SP349125 | 34.9 | 125 | 396 | Air/Oil Cartridge | 100 | 680g |
| SP349150 | 34.9 | 150 | 458 | Air/Oil Cartridge | 100 | 778g |
| SP349170 | 34.9 | 170 | 492 | Air/Oil Cartridge | 100 | 824g |
